VIVITEK DW832

$1,699.00

VIVITEK DW832
5000 lumens
WXGA, DLP 5000:1 contrast ratio
Brilliant Colour Technology
4000 hours lamp life (eco mode)
HDMI, VGA x2, display port
Off and Go
Weight only 3.15 Kg
3 years warranty, lamp 1000 hours or 1 year

Description

DW832

Widescreen compact and high brightness projector

Vivitek DX831 DW832 Front

Versatility meets performance

The Vivitek DW832 delivers exceptional digital images with a high degree of vibrancy thanks to 5,000 ANSI lumens of brightness and a contrast ratio of 15,000:1. Featuring native WXGA resolution the DW832 is designed for a wide variety of applications. Their compact size at just 3,2 kg and flexible 1.5x zoom ratio allows for easy transportation between different meeting rooms or classrooms. The DW832 features HDMI/MHL and various connectivity options to fully enjoy multimedia applications of any kind.

Vivitek DX831 DW832 Left Hero
Vivitek DX831 DW832 IO Rear

Key features

  • DLP® technology with BrilliantColor™ for vibrant and rich picture quality
  • 5,000 ANSI lumens of brightness and 15,000:1 contrast ratio for clear, crisp and bright projection
  • Great flexibility with 1.5x zoom
  • 2x HDMI input for high definition content with the same high quality
  • MHL device compatibility for streaming of video and audio content from a compatible mobile device
  • 10W speaker and microphone input ensure you are clearly heard
  • 6 Segment (RYGCWB) color wheel for accurate and detailed images
  • Quick auto search filtering to quickly locate input signal source
  • 3D compatibility with DLP® Link™ and HDMI 1.4b Blu-Ray support for dazzling and realistic life-like images
  • Enhanced environmentally friendly power functions (Eco mode, Auto power off, stand-by mode) to increase lamp life and power savings
DLP® Technology

DLP® Technology

DLP (Digital Light Processing) is a display technology from Texas Instruments (TI). The technology inside is often referred to as DMD (Digital Micro-Mirrors). It consists of an array of mirrors where each mirror represents a pixel element. For example, a high-definition DLP projector or rear projector with 1920 x 1080 pixel resolution would have over 2 million tiny mirrors. Each mirror is attached to an electronically driven hinge that controls the amount of colored light that is reflected from

BrilliantColor™

BrilliantColor™

BrilliantColor from Texas Instruments is a multi-color processing technology that produces vibrant images. BrilliantColor technology uses up to six colors, instead of just the three primary colors, red, green and blue, to improve color accuracy and brightens secondary colors.

3D Ready

3D Ready

A projector that is 3D Ready can accept a 120Hz frame-sequential 3D signal from a computer. These projectors are not compatible with the HDMI 1.4 3D specification used on 3D Blu-ray players and set-top boxes. 3D ready uses DLP Link Technology from Texas Instruments.

HDMI

HDMI

HDMI (High Definition Multimedia Interface) is an uncompressed, all-digital audio/video interface that supports audio/video sources such as a set-top box, DVD player, A/V receiver, and video monitors such as a digital projector or digital television (DTV). HDMI is backward compatiable with DVI 1.0 specification and supports HDCP.

Native Resolution WXGA (1280 x 800)
Brightness 5000 ANSI Lumens
Contrast Ratio 15000:1
Max. Supported Resolution WUXGA (1920×1200) @60Hz
Native Aspect Ratio 16:10
Lamp Life and Type 2,500 / 3,000/3,500 Hours (Normal/Eco/Dynamic Eco Mode),310W/245W
Display Type Single chip DLP® Technology by Texas Instruments
Chip Size 0.65” DMD
Throw Ratio 1.46- 2.20
Image Size (Diagonal) 25.3″ ~ 317.99″
Projection Distance 1.2-10m
Projection Lens F = 2.42~2.97, f = 20.70~31.05 mm
Zoom Ratio 1.5x
Offset (Based on Full Image Height) 112%
Keystone Correction Vertical +/- 40 Degree
Speakers 10W x 1
Video Compatibility SDTV (480i, 576i) / EDTV (480p, 576p) / HDTV (720p, 1080i, 1080p), NTSC (M, 3.58/4.43 MHz), PAL (B,D,G,H,I,M,N) SECAM (B,D,G,K,K1,L)
I/O Connection Ports VGA-In (15pin D-Sub) (2), HDMI (x2 (with MHL x1)), S-Video, Composite Video, Audio-In (RCA), Audio-In (Mini-Jack), VGA-Out (15pin D-Sub), Audio-Out (Mini-Jack), RJ45, 12v Trigger, RS-232, USB A (for 5V/1.5A power only), USB miniB (Service), Microphone (Mini-Jack)
I/O Connection Ports SDTV (480i, 576i) / EDTV (480p, 576p) / HDTV (720p, 1080i, 1080p), NTSC (M, 3.58/4.43 MHz), PAL (B,D,G,H,I,M,N) SECAM (B,D,G,K,K1,L)
Dimensions (W x D x H) 314 x 216 x 126mm
Weight 3,2 kg
Noise Level 38dB/34dB (Normal/Eco Mode)
Power Supply: AC 100-240V, 50/60Hz Consumption: 320W (Eco. Mode), 410W (Normal Mode), <0.5W (Standby)
3D Ready(DLP link, PC+Video) Yes
Spare Lamp P/N 5811120589-S
Remote Control P/N 5041846400
Standard Accessories VGA Cable, User Manual (CD), Quick Start Guide, Warranty Card (by region), Remote Controller (with battery), AC Power Cord
Optional Accessories Spare Lamp P/N: 5811120589-S , Remote Control P/N: 5041846400
Warranty Standard Warranty: 3 years projector / 1 year on lamp or 1000 hours whichever comes first, Education Warranty: 5 years projector / 3 years on lamp or 2000 hours whichever comes first
UPC Code 813097 021540
