Description

Product Details

• Smart LED Portable Projector with Harman Kardon Speakers

• Patented 3-in-1 smart stand for 360° projection

• Side projection with H/V keystone correction & 4-corner adjustment

• Powerful sound delivered by dual Harman Kardon speakers

• Up to 4 hours of battery life with power bank compatibility

• Smart features: Wi-Fi screen mirroring, USB-C streaming, and Bluetooth connectivity

---

Overview

The M1X ultra-portable smart LED projector is designed for entertainment on the go. Weighing less than 1kg, it features the signature patented 3-in-1 smart stand, offering 360° projection angles, a lens cover, and auto power-on. With vivid colors up to 100″ and built-in Harman Kardon speakers, the M1X provides immersive audio-visual enjoyment indoors or outdoors.

Enjoy up to 4 hours of battery life, with additional support for power banks, making it a true portable companion. Its H/V keystone correction and 4-corner adjustment ensure flexible setup, while smart connectivity options such as Bluetooth, Wi-Fi, and USB-C streaming simplify content sharing from mobile devices, including iPhone. You can also connect streaming devices like Chromecast, Apple TV, or Fire TV Stick, powered directly via the M1X’s USB-A port.

---

Specifications

Optical & Display

• Projection System: 0.2″ WVGA

• Native Resolution: 854 × 480

• Brightness: 360 (LED Lumens)

• Contrast Ratio: 120,000:1

• Display Colors: 1.07 Billion

• Light Source: LED

• Light Source Life: 60,000 hrs

• Lens: F=1.7, f=5.5mm

• Projection Offset: 100% ±5%

• Throw Ratio: 1.2

• Optical Zoom: Fixed

• Image Size: 24″–100″

• Throw Distance: 0.64 – 2.66 m (38″ @ 1m)

• Keystone: H ±40°, V ±40°

• Audible Noise: 26 dB (Normal) / 25 dB (Eco)

• Local Storage: 16GB (12GB available)

• Input Lag: 73 ms

• Resolution Support: VGA (640 × 480) to Full HD (1920 × 1080)

• HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p

• Horizontal Frequency: 15K – 102KHz

• Vertical Scan Rate: 23 – 120Hz

Inputs

• HDMI: 1 (HDMI 1.4 / HDCP 1.4)

• USB Type-C: 1 (5V/1.5A)

• Audio In (Bluetooth 4.2): 1

• USB Type-A: 1 (USB2.0 Reader)

• Wi-Fi Input: 1 (5G n)

Outputs

• Audio Out (3.5mm): 1

• Audio Out (Bluetooth 4.2): 1

• Speaker: 3W Cube ×2 (Full range ×2)

• USB Type-A (Power, USB2.0, 5V/1.5A, shared with Input): 1

Control

• USB Type-A (Service, shared with Input): 1

General

• Power Supply: Adaptor (Input: 100–240V; Output: 19VDC / 3.26A)

• Battery: 12,000mAh (4000mAh ×3, 3.7V) — 2.5 hrs (Normal) / 3 hrs (Eco)

• Power Consumption: 35W (Normal) / <0.5W (Standby)

• Operating Temperature: 0 – 35℃

• Carton: Color

• Net Weight: 0.8 kg

• Gross Weight: 1.87 kg

• Dimensions (W × D × H): 166 × 138 × 54 mm (with adjustment foot)

• Packing Dimensions: 220 × 190 × 125 mm

• OSD Languages: 23

• User Guide Languages: 20

---

Accessories

Standard

• Power Cord: 1

• USB-C Cable (1m): 1

• Remote Control (BT without backlit): 1

• Quick Start Guide: Yes
