NEC NP-P605ULG
$6,099.00
- Description
Description
Versatile, maintenance-free, entry-level installation projectors with excellent quietness
Filter-free Structure with NEC’s Original Cooling System
NEC’ s Unique Sealed LCD Panel Cooling System
High dustproof performance is achieved by NEC’s proprietary sealed jet impingement cooling structure. Due to its excellent dustproof performance, this projector does not have the cumbersome filters that ordinary LCD projectors require. The new laser-based LCD projector offers better TCO (total cost of ownership) with less maintenance.
Super Silent Design Utilising a Sealed Structure
The unique cooling system not only improves the dustproof performance but also reduces the noise of the fan. This quiet design achieves excellent quietness of 19 to 22 dB in ECO mode. Even in a very quiet meeting room or classroom, the presence of the projector is not felt.
Maintains the set brightness for a long time
The projector is equipped with a “constant brightness mode” that detects changes in brightness due to aging and automatically adjusts the output to keep the brightness constant. This makes it possible to project with stable brightness for a long time.
A Long-life Laser Diode is Provided in the Light Module
Advanced laser technology delivers a reliable light source up to 20,000 hours.
Self Colour Correction
This function compensates for the natural colour shift that occurs with age and adjusts to natural and suitable colours automatically according to the number of hours used.
Advanced Installation Functions and Connectivity
Lens Shift
Lens shift provides greater flexibility when determining the installation location.
Tilt-free
The projector can be rotated freely (360°) to orient the image depending on the installation requirements.
Portrait mode
Allows the projector to be rotated (and screen if necessary) to a vertical alignment so that portrait content can be viewed without black bars on the side when landscape mode is used.
Built-in HDBaseT
Simplify your installations with HDBaseT, which is optimised for video applications and supports uncompressed full HD digital video, audio, Ethernet, power and various control signals. With only a single cable (up to 100 m) to run, infrastructure and labour costs are reduced, installations are significantly easier, and there is no cable clutter to manage. With uncompressed HD video support, images have never been more stunning.
Dual HDMI Inputs
The wide selection of inputs includes HDMI with HDCP for connecting to high-definition sources such as Blu-ray players, cable boxes, satellite receivers and personal computers.
Support for 4K Input
The built-in HDMI and HDBaseT input terminals support up to 4K video for display of ultrahigh resolution video.
Advanced Networking Capabilities
MultiPresenter
This projector is compatible with the NEC MultiPresenter application, so multi-screen projection is possible via the network (wired LAN / wireless LAN).
Multi-screen Projection Function *1
The multi-screen projection function allows for the sharing of screens of multiple devices on various split-screen displays via a wireless or wired LAN. Display information from up to 50*2 PCs, tablet PCs, smart phones, and other network connected devices on a multi-screen display of up to 16 screens. Easily share screens and information regardless of device or operating system.
- *1:Requires the optional wireless LAN module for wireless connection. PCs, smart phones and tablets require the download and installation of our MultiPresenter software.
- *2:The connection of 50 devices to the network requires construction of a wireless LAN environment, such as the use of a separate access point.
Simultaneous Dual Image Display (PIP)
With this projector, it is possible to project two images with a single projector by displaying a small sub-display within the main display. Furthermore, the sub-display display position can be changed and the main display and sub-display images can be swapped.
Sub input position
It is possible to select from four sub-display positions.
Picture swap
The videos in the main display and sub-display will be switched.
Combination table of main display and sub-display terminals
| Sub-display | |||||||
|---|---|---|---|---|---|---|---|
| HDMI 1 | HDMI 2 | HDBaseT | COMPUTER | LAN | USB-A | ||
| Main Display | HDMI 1 | No | No | Yes | No | No | |
| HDMI 2 | No | No | Yes | No | No | ||
| HDBaseT | No | No | Yes | No | No | ||
| COMPUTER | Yes | Yes | Yes | No | No | ||
| LAN | Yes | Yes | Yes | Yes | No | ||
| USB-A | No | No | No | No | No | ||
| Model | NP-P605UL | NP-P525UL | NP-P525WL | ||
|---|---|---|---|---|---|
| Method | Three primary colour liquid crystal shutter projection | ||||
| Specifications of main parts | |||||
| Liquid crystal panel | Size | 0.64 inch LCD with MLA× 3 (aspect ratio: 16:10) | |||
| Pixels *1 | 2,304,000 (1,920 dots× 1,200 lines) | 1,024,000 (1,280 dots× 800 lines) |
|||
|
Projection lenses |
Zoom | Manual | |||
| Focus | Manual | ||||
| Zoom ratio | 1.6 | ||||
| Throw ratio | 1.23 to 2.0 | ||||
| F-number/ focal length |
F= 1.5 to 2.1 f= 17.2 mm to 27.6 mm | ||||
| Lens shifting | Manual ( H = +/ −29% / V= 0% to +60%) | ||||
| Light source | Blue Laser diode | ||||
| Light source (laser diode) life *2 | 20,000H | ||||
| Optical unit | Integrator, dichroic mirror, XDP | ||||
|
Light output *3 *4 |
ECO MODE [OFF] | 6,000 lm (6,200 centre lm) *5 | 5,000 lm (5,200 centre lm) *5 | ||
| ECO MODE [ECO] | Approx. 60% | ||||
| ECO MODE [LONG LIFE] | Approx. 50% | ||||
| Contrast ratio *4 (all white/all black) | 600,000 : 1 with Light Adjust | 500,000 : 1 with Light Adjust | |||
| Image size | 30 to 300 inches | ||||
| Colour reproduction | 10-bit signal processing, 1.07 billion colours (Viewer, Network, 16.7 milion colours) | ||||
| Quietness (ECO MODE [ECO] / ECO MODE [OFF]) |
19 dB / 25 dB to 28 dB (high bright) |
22 dB / 24 dB to 27 dB (high bright) | |||
| Synchronisation
range |
Horizontal | 15 to 100 kHz (RGB: 24 kHz or over) | |||
| Vertical | 50 to 120 Hz | ||||
| Max. display resolution (horizontal× vertical) |
Up to 4K@30 Hz (3,840 x 2,160) with Advanced AccuBlend,
Pixel clock frequency: less than 300 MHz (HDBaseT: 300 MHz) |
||||
| Keystone
correction |
Horizontal | Manual, approx. ± 30 max degrees | |||
| Vertical | Manual, approx. ± 30 max degrees | ||||
| Input/output connectors | |||||
| Computer/ component | Video input | Mini D-Sub 15-pin× 1 | |||
| Audio input | Stereo mini jack× 1 | ||||
| Audio output | Stereo mini jack× 1 (Selected from: Computer / HDMI) | ||||
| HDMI | Video input | Type A HDMI connector× 2 | |||
| Audio input | Yes | ||||
| HDBaseT/ Ethernet Port | Video input | RJ45 × 1, 100BASE-TX / HDBaseT, Lip Sync Deep Colour,
Colourimetry Support: RGB, YCbCr444, YCbCr422 |
|||
| Audio input | Yes | ||||
| PC control connector | D-Sub 9-pin× 1 (4800 / 9600 / 19200 / 38400 bps) | ||||
| USB port | USB type A× 1 for USB (5.0 V/ 2.0 A power supply) | ||||
| Ethernet/LAN | RJ-45 × 1 | ||||
| Wireless LAN Port (Optional) | USB× 1 | ||||
| Built-in speaker | 20 W × 1 | ||||
|
Usage environment |
Operating temperature: 5 to 40°C *6, Operating humidity: 20 to 80% (with no condensation) |
||||
| Storage temperature: −10 to 50°C, Storage humidity: 20 to 80% (with no condensation) | |||||
| Operating altitude: 0 to 2,600 m (1,600 to 2,600 m: Set [FAN MODE] to [HIGH ALUTITUDE]) |
|||||
| Power supply | 100 − 240 V AC, 50/60 Hz | ||||
|
Power consumption |
ECO MODE [OFF] | 367 W (100 to 130 V)
357 W (200 to 240 V) |
330 W (100 to 130 V)
320 W (200 to 240 V) |
320 W (100 to 130 V)
312 W (200 to 240 V) |
|
| ECO MODE [ECO] | 261 W (100 to 130 V)
257 W (200 to 240 V) |
240 W (100 to 130 V)
238 W (200 to 240 V) |
232 W (100 to 130 V)
230 W (200 to 240 V) |
||
| ECO MODE [LONG LIFE] | 230 W (100 to 130 V)
227 W (200 to 240 V) |
242 W (100 to 130 V)
240 W (200 to 240 V) |
234 W (100 to 130 V)
232 W (200 to 240 V) |
||
| NETWORK STANDBY | 1.4 W (100 to 130 V) / 1.6 W (200 to 240 V) | ||||
| STANDBY *7 | 0.13 W (100 to 130 V) / 0.19 W (200 to 240 V) | ||||
| Rated input current | 5.5 A to 2.3 A | 5.1 A to 2.1 A | 5.0 A to 2.1 A | ||
| Dimensions (W× H× D) | 480 ×122 ×407 mm (Net dimensions, not including protruding parts), 591 ×259 ×491 mm (Gross dimensions) |
||||
| Weight | 9.7 kg (Net weight), 12.8 kg (Gross weight, with box) | ||||
- *1:Effective pixels are more than 99.99%.
- *2:Time at which the laser light source is at half brightness; not a guaranteed time.
- *3:This is the light output value (lumens) when [ECO MODE] is set to [OFF] and [PRESET] is set to [HIGH-BRIGHT]. The brightness decreases when [ECO MODE] is set to [ECO] or [LONG LIFE] ([ECO]: about 60%, [LONG LIFE]: about 50%). If any other mode is selected as the [PRESET] mode, the light output value may drop slightly.
- *4:Compliant with ISO21118-2012.
- *5:Measured at centre area of projector screen.
- *6:35 to 40°C – “Forced eco mode”.
- *7:Value as measured by NEC. All wired network ports are connected and active.
- These specifications and the product’s design are subject to change without notice.
