SE-1200 (SE1200MU + RMC-260)



Switcher style controller


Allows user to control SE-1200MU by keys for quick and easy operation.


Supports user memory


Save user behavior to user memory keys for easy conversion of custom settings.


Easy connection


RS-232 interface for communication between RMC-260 and SE-1200MU


RMC-260 SE-1200MU Digital Video Switcher remote controller
Communication Interface RS-232
Baud Rate 38400 ODD
Update USB
Power Supply Input AC 100 ~ 240V Switching Adaptor
Output DC 12V
Power Consumption 5W
Operating Temperature 0~40 °C
Humidity 10% to 90% (non condensing)
Dimension (LxWxH) 430 x 261 x 70 mm
Net Weight 1.3 kg
Power DC 12V, 0.5A
Accessory RS-232 Transmission Cable, Power Adapter, Thank You Card
What’s in the Box 1 x RMC-260 product
1 x AD Switch DC 12V
1 x DB9P TO DB9P Cable
1 x Thank You Card




Switcher with distance control


Switch over IP, external control or RMC-260 control panel

Suitable for medium-sized productions


Supports 6 HD inputs and 4 outputs in HDMI and SDI.


Stunning video effect enrich the scene


Two down stream keyers(DSK) and two picture-in-picture(PIP) generators combined with a dual chromakeyer give you enough freedom to be creative.


Built-in animation and backgrounds


Pre-saved multiple sets of animated stinger transitions and virtual set backgrounds.

Simple-to-use physical hardware interface


Intuitive control panel RMC-260 makes switching a piece-of-cake for new and experienced users.

Professional 10-bit processing switcher


Providing you the best and professional quality of video processing.

Supports XPT (Cross Point Assignment)


A XPT feature giving you a much easy use on the live production.


SE-1200MU 6 Input Rackmount HD Switcher
Video Standard HD
Video Format 1080i 50/59.94/60Hz
720p 50/59.94/60Hz
Video Processing SDI: 4:2:2
HDMI: YUV 4:2:2 10 bit, RGB 4:4:4
Input Routable / Crosspoint All 6, repeatable
Video Input 4x HD-SDI
2x HDMI (RGB/YUV, 1080i/1080p/720p)
Computer Graphic Interface 2 via HDMI
Video Output 2x HD-SDI
2x HDMI assignable:
PGM(w/DSK 1&2), PGM(w/DSK 1), PGM Clean, PVW(w/o DSK), multi-view, Input 1-6
Built-in Multi-view Monitoring Out HDMI & SDI assignable, Ethernet (MJPEG)
Analogue Audio Input 2x Balanced XLR
Analogue Audio Output N/A
Digital Embedded Audio Support Input 2 channels, Output 2 channels
A+V Switching Yes
Chromakey 2
USK 2x Keyer support Chromakey/ Linear/ Luma Key
DSK 2x DSK support Lumakey/ Linear key (Key / Fill)
Picture in Picture 1
Still Store 500
Effects FTB, Cut, 32 Wipe with
Transition Preview Full transitions preview
Sync / Reference In/Out Built-in Genlock (internal)
Tally Output 1x D-sub 15pin, dual color
PC Remote Control Ethernet (free Window software)
RS-422/ RS-232
Special Features Motion JPEG Multi-view streaming
(120 memory preset, BGD Transition on/off option)
Free Virtual Set and Stinger transition included
Chassis 2 units, 1RU rack-mount mainframe
Dimension (LxWxH) 440 x 215 x 49 mm
Weight 1.5 kg
Power DC 12V, 19W
Operating Temp. Range 0~40 °C
Options CB-46/47/60/61/62
What’s in the box 1 x SE-1200MU product
1 x AD Switch DC 12V
1 x DB9P TO DB9P Cable
1 x Thank You Card
2 x 1U Rack Mount Ear
6 x M4 Screws for Rack Mount Ear
