4 Input HD digital video switcher
SDI and HDMI inputs on a budget
The SE-650 is Datavideo’s most affordable SDI+HDMI switcher available. With 2 SDI inputs and 2 HDMI inputs, the SE-650 is compatible with both professional and consumer-grade cameras while being one of the least expensive switchers in our catalog.
Easy on the outside. Professional on the inside.
The SE-650’s intuitive control panel makes switching a piece-of-cake for experienced users, as well as for beginners such as volunteers and students. Though it’s geared for novice users, the SE-650 is packed with advanced features such as lumakey and chromakey.
Stunning video effect enrich the scene
Down stream keyers(DSK) , up stream keyers(USK) and picture-in-picture(PIP) generators combined with a dual chromakeyer give you enough freedom to be creative.
Built-in audio mixer
The SE-650’s built-in audio mixer means that you’ve got everything you need to control your audio input levels. For most productions, this means that there’s no need to buy a separate external audio mixer.
Built-in animations and backgrounds
Choose between a variety of pre-saved animated stinger transitions and virtual set backgrounds.
You can save a complex process into a user memory, turning multiple tasks into a one-finger job.
|SE-650 4 Input HD digital video switcher|
|Video Format||1080i 50/59.94/60Hz
|Video Processing||SDI: 4:2:2
HDMI: YUV 4:2:2 10 bit, RGB: 4:4:4
|Input Routable / Crosspoint||All 4, repeatable|
|Video Input||2x HD-SDI
|Computer Graphic Interface||2 via HDMI|
|Video Output||2 x HDMI (1 is MV, 1 is Assignable)
1 x HD-SDI (Assignable)
|Built-in Multi-view Monitoring Out||HDMI & SDI assignable|
|Analogue Audio Input||1 x Stereo RCA (L/R)
2 x Mono Microphone
|Analogue Audio Output||1 x Stereo RCA (L/R)
1 x Stereo headphone (Mini Jack with volume control)
|Digital Embedded Audio Support||Input 2 channels, Output 2 channels|
|USK||2x Keyer support Chromakey/ Linear/ Luma Key|
|DSK||1x DSK support Lumakey/ Linear key (Key / Fill)|
|Picture in Picture||1|
|Effects||FTB, Cut, 32 Wipe with border|
|Transition Preview||Full transitions preview|
|Sync / Reference In/Out||Built-in Genlock (internal)|
|Tally Output||1x D-sub 15pin, dual color|
|PC Remote Control||DVIP (Ethernet)|
|Built-in Audio Mixer||Yes, 4 channels|
|Special Features||Free Virtual Set and Stinger transition included|
|Dimension (LxWxH)||400 x 250 x 82 mm|
|Power||DC 12V, 29W|
|Operating Temp. Range||0~40 °C|
|What’s in the Box||1 x SE-650 product
1 x AD Switch DC 12V with AC Cord
1 x Thank You Card
