Vivitek DH385ST Projector

The DH385ST features a high brightness and 30,000:1 contrast ratio to deliver 250″ image even in any bright environment. Compact size, low weight, and quick installation make this series ideal for classrooms and meeting rooms. With top-side cover and energy-saving design, this series is easy to replace lamp and has a long lamp life up to 15,000 hours. Furthermore, DX335ST, DW355ST, DH385ST with its short throw design can project up to a 100-inch large and clear image from a short distance to save the space.

Description

Key Features

DLP Darkchip3 & BrilliantColor Technology

The DH385ST supports DLP® and BrilliantColor™ technologies for distinct and vibrant images. The 6-segment (RGBYCW) color wheel not only makes the image more vivid and saturated, but also reproduces color performance.

Bright Images in Any Environment

Packed with up to 4,000 lumens of brightness and a high contrast ratio 30,000: 1, the DH385ST provides sharp and bight images in any environment with ambient light.

Potable & Lightweight

Featured under 3kg, the DH385ST is potable and easy to carry and install between home and school or office.

Large Image

The DH385ST with its short throw design can project up to a 100-inch large and clear image from a short distance to save the space.

H/V Keystone & 4 Corner

The DH385ST supports vertical / horizontal keystone correction and 4-corner geometric adjustment, allowing for virtually unlimited mounting flexibility.

HDR and HDMI 2.0

The DH385ST is capable of receiving and displaying HDR meta data and can provide a brilliant visual experience with more detail and texture when projected over long distance. With an HDMI 2.0 interface, this projector
also supports 4K signals.

Specifications

Display



Projection System

1-Chip DLPTM 0.65 inch

Resolution

1080p (1920 x1080)

Light Source

UHP Lamp





Optics



Brightness

4,000 lm

Brightness Uniformity

80%

Contrast Ratio

30,000:1 (Full On/Off)

Light Source Life

4,000 hrs (Normal) / 5,000 hrs (Eco) / 15,000 hrs (Long Eco)

Lens Type

Fixed

Zoom Ratio

Fixed

Lens Throw Ratio

0.496 : 1

Lens Shift – Horizontal (Full Image Width)

N/A

Offset (Full Image Width)

116%





Geometry Adjustment



Keystone Correction

Yes (H/V)

Four Corner Adjustment

Yes





I/O Terminal



HDMI

1.4a x1 / 2.0 x1

DisplayPort

N/A

SDI

N/A

DVI-D

N/A

YPbPr

N/A

D-Sub

In x1 / Out x1

3D Sync

N/A

RJ45

N/A

RS-232

In x1

Wire Remote

N/A

Speaker

10W x1

USB

Type A (Power Only 5V/1.5A) x1

12V Trigger (mini Jack)

N/A

5 BNC

N/A

Audio

Audio-In (Mini-Jack) x1 / Audio-Out (Mini-Jack) x1





System



Power Supply

AC 100-240V 50/60Hz

Power Consumption ±5%

295W (Normal) / 210W (Eco)

Standby Power

< 0.5W

Acoustic Noise ±5%

Normal 36dB / Eco 27dB

Dimension ±2%

313 x 236 x 114 mm

Weight ±1kg

2.9 kg

3D Display

Active / Passive

24×7 Operation

N/A

Dust Proof*4

N/A

Operation Oreinetation

Up & Down (lamp life not gurantee)

Operation Environment

Temp. 5~40˚C / Humidity10~85%

Storage Environment

Temp. -10~60˚C / Humidity 5~95%
