ViewSonic PG707W
$1,199.00
DLP, 3D-Ready (for PC & BluRay), 4000 ANSI Lumens, up to 20,000 lamp hours, WXGA (1280×800), 22,000:1 (DCR), 1.3x Zoom, 10W speaker, Keystone: +/-40’
(H/V), VGA, s-video/composite X 1, HDMI*2 (MHL X1), RS232 & RJ45, 2.4kg
- Description
Description
The ViewSonic® PG707W projector features 4,000 lumens, WXGA 1280 x 800 native resolution, an intuitive, user-friendly design, and a sleek white chassis. Exclusive SuperColor™ technology offers a wide color gamut for beautiful image production in nearly any environment. An energy-saving SuperEco™ feature reduces power consumption and extends the lamp life by up to 20,000 hours. A 10W speaker delivers incredibly clear and audible sound, while a top lamp door enables easy access for lamp maintenance. The PG707W is the ideal high brightness projector for use in both classroom and corporate settings.
SUPERCOLOR: AMAZING COLOR ACCURACY
ViewSonic’s proprietary SuperColor™ Technology features an exclusive 6-segment color wheel and dynamic lamp control capabilities, providing a wide color range and stunningly beautiful images.
BRIGHT IMAGES IN ANY ENVIRONMENT
Packed with 4,000 lumens and a high contrast ratio, this projector is guaranteed to produce bright images in nearly any environment – even in rooms with high ambient light.
ENERGY-EFFICIENT SUPERECO ™
SuperEco™ mode allows users to dim projection brightness by up to 70%, thereby reducing the lamp’s power consumption while extending lamp life—a great energy-saving design that lowers the total cost of ownership (TCO).
NETWORK MONITORING & CONTROL
IT admin can monitor, schedule, and manage the projector remotely, as well as receive projector status alerts, with the integrated Crestron® e-Control™ system and RoomView Express™ management software. Because this projector is Crestron® and AMX® certified, IT admin can control and monitor the projector for any size campus or enterprise.
CONVENIENT MOUNTING FLEXIBILITY
A 1.3x optical zoom lens provides more mounting flexibility over a standard lens so you can place your projector where you want and still get big, vivid images. For a perfectly proportioned picture every time, horizontal/vertical keystone correction and a corner adjustment feature eliminate crooked and distorted images.
REDUCED INPUT LATENCY
This projector delivers smooth images without delay. Its ultra-low 16ms input latency provides faster frame-by-frame action.
VERSATILE CONNECTIVITY
HDMI, USB, and VGA connections provide the versatility to connect to a wide variety of computing and multimedia devices.
PEACE OF MIND
ViewSonic offers one of the industry’s best overall projector warranties with 3-year limited parts and labor, 1-year lamp, and first year free Express Exchange® service* for an added value worth up to $150**.
*One year Express Exchange® Service requires product registration. **Up to $150 added value over competitive models with 1-year warranty and based on extended warranties from manufacturers and not third party warranty providers.
RESOLUTION
1280 x 800
THROW RATIO
1.21-1.57
THROW DISTANCE
2.6 – 33.1 ft / .8 – 10.1 m
BRIGHTNESS (LUMENS)
4,000 ANSI
DISPLAY
TYPE
DLP Lamp
RESOLUTION TYPE
WXGA (1280×800)
RESOLUTION
1280 x 800
BRIGHTNESS (LUMENS)
4,000 ANSI
DISPLAY SIZE (IN.)
30 – 300 in. / 0.76 – 7.62 m
THROW DISTANCE
2.6 – 33.1 ft / .8 – 10.1 m
THROW RATIO
1.21-1.57
KEYSTONE
Vertical (± 40º) / Horizontal (± 40º)
LENS
1.3x optical zoom
LIGHT SOURCE (WATT)
203
LIGHT SOURCE LIFE, NORMAL (HOURS)
6000
LIGHT SOURCE LIFE, DYNAMIC ECO-MODE (HOURS)
20000
COLOR DEPTH
1.07 Billion Colors
DYNAMIC CONTRAST RATIO
22,000:1
ASPECT RATIO
16:10
VIDEO SIGNAL
FREQUENCY HORIZONTAL
15K~105KHz
COMPATIBILITY
PC RESOLUTION (MAX)
1920 x 1080
PC RESOLUTION (MIN)
640 x 480
MAC® RESOLUTION (MAX)
1920 x 1080
MAC® RESOLUTION (MIN)
640 x 480
CONNECTOR
USB 2.0 TYPE A
1
ETHERNET LAN (RJ45)
1
3.5MM AUDIO OUT
1
3.5MM AUDIO IN
1
CONTROL (RS232)
1
HDMI 1.4 (WITH HDCP 1.4)
2
VGA IN
1
VGA OUT
1
COMPOSITE RCA VIDEO IN
1
AUDIO
INTERNAL SPEAKERS
10W (x1)
POWER
VOLTAGE
100-240V+/- 10%, 50/60Hz AC
CONSUMPTION (TYPICAL)
280W
STAND-BY
<0.5W
CONTROLS
PHYSICAL CONTROLS
Keypad, Power key
ON SCREEN DISPLAY
Display, Image, Power Management, Basic, Advanced, System, Information (See user guide for full OSD functionality)
OPERATING CONDITIONS
TEMPERATURE
32-104º F (0 – 40º C)
ADDITIONAL HARDWARE
KENSINGTON LOCK SLOT
1
WEIGHT (IMPERIAL)
NET (LBS)
5.1
GROSS (LBS)
7.8
WEIGHT (METRIC)
NET (KG)
2.3
GROSS (KG)
3.5
DIMENSIONS (IMPERIAL) (WXHXD)
PACKAGING (IN.)
16.3 x 6.6 x 11.7
PHYSICAL (IN.)
11.6 x 4.3 x 8.6
DIMENSIONS (METRIC) (WXHXD)
PACKAGING (MM)
415.0 x 168.0 x 297.0
PHYSICAL (MM)
294.0 x 110.0 x 218.0
GENERAL
REGULATIONS
cTUVus
PACKAGE CONTENTS
PG707W projector, power cable, VGA cable, remote control, Quick Start Guide
WARRANTY
Three-year limited warranty on parts and labor, 1-year limited warranty on lamp, 1st year free Express Exchange® service. (One year Express Exchange Service requires product registration).
RECYCLE/DISPOSAL
Please dispose of in accordance with local, state or federal laws.
DIMENSIONS
11.6 x 4.3 x 8.6 in / 294.0 x 110.0 x 218.0 mm
- Control Panel
- Elevation Foot
- Zoom Ring
- IR Remote Sensor
- Projection Lens
- VGA In
- HDMI (x2)
- Audio In/Out
- USB 2.0 Type A
- AC In
- Monitor Out
- RCA Video In
- LAN
- Kensington® Lock Slot
- RS232
